Roksan Caspian Integrated - Integrated Amplifier

Description

The Roksan Caspian Integrated Amplifier is a Class AB integrated amplifier built with independent power supplies for each channel and a fully symmetrical circuit design, delivering a smooth, powerful, and grippy sound at a high-end level. It can also be paired with the Caspian Power Amplifier for a multi-amplification system.

Features

• Independent power supplies per channel with fully symmetrical circuit design
• On-board output protection with high current relays and short circuit protection
• Five line inputs plus tape input/output, first input switchable to balanced XLR
• Independent power supply for the preamplifier stage
• Thermally controlled, fan-assisted heat-sink cooling
• Motorised volume control with LED position indicator
• -20dB mute function and 2 pre-amplifier outputs
• Power supply failure detection and pre-power-up diagnostic check

Specifications

• Amplifier Type: Class AB
• Inputs: 5x RCA (CD input switchable to gold-plated XLR)
• Input Impedance: 47 ohms
• Power Output (per channel): >85W @ 8Ω / >125W @ 4Ω
• Gain: 40dB overall
• Signal-to-Noise Ratio: Line 108dB
• Power Consumption: 2-channel: <330W @ 8Ω, <550W @ 4Ω
• Frequency Response: -3dB, <1Hz–90kHz
• Dimensions (W x H x D): 432 x 80 x 330mm (incl. feet)
• Weight: 11 kg
