Procella V21 - Subwoofer

The Procella V21 Bass Engine is a passive subwoofer positioned above the V18 for reference level commercial and residential cinemas. Twin 21 inch long throw professional drivers in the V-Loaded configuration share a 255 litre sealed cabinet, reducing distortion and cone movement while improving transient speed. It produces 139 dB continuous and 145 dB peak with extension to 18 Hz, and needs an external amplifier with DSP or PEQ control, such as a Trinnov processor, for room correction.

• Twin 21 inch long throw professional drivers with 4.5 inch voice coils and neodymium magnets
• V-Loaded driver configuration for lower distortion and faster transients
• Aluminium demodulation rings to reduce distortion
• 139 dB continuous and 145 dB peak output
• Extension to 18 Hz at high output
• Power handling of 2 x 1,700 W continuous
• DSP settings for against wall, in baffle wall and corner placement
• Damper feet, protective grille and installation guide included

• Type: Passive sealed subwoofer, V-Loaded
• Frequency response: −3 dB at 18 Hz
• Maximum SPL: 139 dB continuous, 145 dB peak
• Drivers: 2 x 21 inch long throw professional drivers with 4.5 inch voice coils, neodymium magnets and aluminium demodulation rings
• Enclosure: 255 litre sealed box
• Sensitivity: 106 dB (1 W / 1 m)
• Impedance: 2 x 8 ohms nominal
• Power handling: 2 x 1,700 W continuous, 2 x 3,200 W peak
• Connectivity: Dual heavy duty gold plated binding posts
• Amplifier: External, sold separately
• Construction: Void free, internally cross braced MDF with semi matte textured black paint
• DSP settings: Against wall, in baffle wall, in corner
• Dimensions (W x H x D): 1050 x 620 x 670 mm (41.4 x 24.4 x 26.4 in)
• Weight: 81 kg (179 lb)
• Shipping carton: 1200 x 850 x 800 mm (47.25 x 33.5 x 31.5 in) palletised crate, 99 kg (219 lb)
• Included: Damper feet, installation guide, protective grille
• Assembly: Belgium, 100% QC tested
