Paradigm H55-R In-Ceiling Speaker

Description

The Paradigm H55-R is a custom-install in-ceiling speaker from the CI Home series, built for superior sound and easy installation with a discreet, bezel-free micro-perf grille. A pure-titanium tweeter dome and mineral-filled polypropylene bass/midrange driver deliver clear dialogue and extended bass, while a rigid ABS chassis and clamp system resist unwanted resonance from walls and ceilings.

Features

• PTD pure-titanium tweeter dome, ferro-fluid damped and cooled
• Mineral-filled polypropylene bass/midrange cone
• Bezel-free micro-perf grille, magnetically attached (paintable, no masking needed)
• High-strength ABS chassis and clamp system for solid installation
• Pocketed screw holes and easy-access binding posts (banana plug, pin, or bare wire)

Specifications

• Design: 2-driver, 2-way in-ceiling
• Crossover: 2nd-order electro-acoustic at 3.0 kHz
• Frequency response: ±2dB, 75 Hz–20 kHz (on-axis)
• High frequency driver: 1x 3/4" PTD dome
• Mid/bass driver: 1x 5.5" mineral-filled polypropylene cone
• Low frequency extension: 60 Hz
• Sensitivity: 88 dB (room) / 84 dB (anechoic)
• Impedance: 8 ohms compatible
• Recommended amplifier power: 15–70W
• Maximum input power: 40W
• Finish: White, paintable grille
• Overall dimensions: 19.7cm diameter x 8.6cm depth
• Cut-out diameter: 17.1cm
• Minimum mounting depth: 7.0cm
• Weight: 1.2 kg
