Monitor Audio Radius 200 - Centre Speaker

AED 1,715.00(Exc. Tax)

RADIUS 200 Designed for rack or shelf mounting in a dedicated home theatre system. Placed front and centre in a serious AV system, twin 4" C-CAM mid/bass drivers astride a 1" C-CAM...

High Gloss Black LacquerHigh Gloss Black Lacquer
Satin WhiteSatin White
Walnut Real Wood VeneerWalnut Real Wood Veneer
Description

RADIUS 200

Designed for rack or shelf mounting in a dedicated home theatre system. Placed front and centre in a serious AV system, twin 4" C-CAM mid/bass drivers astride a 1" C-CAM tweeter result in the compact Radius 200 anchoring the entire sound field with life-like fidelity.

Technology

  • Ultra compact dedicated centre speaker
  • Dual C-CAM bass drivers with C-CAM tweeter in MTM style configuration - Radius features bass drivers with concave cone profiles, introduced by Monitor Audio top-of-the-range Platinum speakers and applied subsequently to Gold GX.  Extensive research and FEA modelling have allowed Monitor Audio to perfect the relationship between the radiating diaphragm and its motor design, introducing larger motor sizes and voice coils for increased excursion, higher power capability and reduced distortion.
  • C-CAM Gold Dome tweeter - optimised to deliver the finest and widest performance within the compact Radius cabinets. It benefits from a more efficient rear-venting design, releasing air trapped and compressed at the back of the tweeter dome, and guiding it around the drive assembly to a rear-loading chamber.
  • HiVe II port design - Straight from Platinum’s design blueprint, the HiVe reflex port makes its Radius debut. It’s shaped to have the same effect on airflow as a gun-barrel on a bullet. Rifled grooves inside the port help to accelerate the flow and reduce turbulence, so air moves in and out of the port more efficiently, for a faster more dynamic bass response.
  • Single through-bolt driver fixing provides mechanical de-coupling and enhanced mid-band clarity and resolution. The through-bolts also act as rigid cross bracing to give a very solid non-resonant cabinet.

SPECIFICATIONS

Frequency Response

60 Hz — 35 kHz

Sensitivity (1W@1M)

86 dB

Nominal Impedance

6 ohms

Power Handling (RMS)

100 W

System Power Handling (RMS)

150 W

Recommended Amplifier Requirements

40 — 150 W

Maximum SPL

106 dBa

Bass Alignment

Bass reflex - Rear ported

Drive Unit Complement

  • 2 x 4" (100 mm) C-CAM cone bass/mid driver
  • 1 x 1" (25 mm) C-CAM Gold Dome tweeter

Cabinet Dimensions (H x W x D)

125 x 330 x 140 mm

Cabinet Dimensions (Including Grille and Terminals (H x W x D))

125 x 330 x 164 mm

Weight

3.6 kg (7 lb 14 oz)

Sold As

Single Unit

Additional Information
Color

High gloss black lacquer, Satin white, Walnut real wood veneer
