Martin Logan Motion FX Surround Speaker (Pair)

Description

The Motion FX is a dedicated wide-dispersion surround speaker with dual Folded Motion tweeters and a Folded Motion Cascading Bass-Reflex Port for deep, detailed bass response. It's voice-matched with MartinLogan's ESL speakers for a seamless surround sound experience.

Features

• Dual Folded Motion tweeters with low-mass diaphragms for minimal distortion and fast response
• Wide, controlled dispersion for a realistic, well-defined soundstage
• Folded Motion Cascading Bass-Reflex Port for deep, detailed bass
• Voice-matched with MartinLogan ESL speakers

Specifications

• Frequency response: 70–25,000Hz ±3dB
• Recommended amplifier power: 20–160 watts per channel
• Horizontal dispersion: 160°
• Vertical dispersion: 80°
• Sensitivity: 91dB/2.83V/meter
• Impedance: 4Ω, compatible with 4, 6, or 8Ω rated amplifiers
• Crossover frequency: 4,500Hz
• High frequency transducer: two 1in x 1.4in (2.6cm x 3.6cm) Folded Motion transducers with 5.25in x 1.75in (13.3cm x 4.4cm) diaphragm
• Low frequency transducer: 5.25in (13.3cm) paper cone with cast aluminium basket, non-resonant asymmetrical chamber, rigid structured dust cap, folded bass reflex port
• Components: custom air core coil inductors, polyester film capacitors in series, low DF electrolytic capacitors in parallel, system thermal/current protection
• Inputs: push style with banana jacks
• Weight: 9.5lb (4.4kg)
• Dimensions: 11.1in x 12in x 6in (28.2cm x 30.5cm x 15.2cm)
