Martin Logan Motion 8i Center Speaker - (Piece)

Description

The Motion 8i is a compact center channel speaker featuring a Folded Motion tweeter, dual 4in paper cone woofers, and a proprietary Vojtko crossover network in an affordable gloss black package. Flexible mounting options let it sit horizontally or vertically on a tabletop or wall, making it ideal for placement around a wall-mounted flat screen TV.

Features

• Folded Motion tweeter with low-mass diaphragm for vanishingly low distortion and fast response
• Proprietary Vojtko crossover network using custom air core coil inductors, low DCR steel laminate inductors, and polyester film/low-DF electrolytic capacitors
• Horizontal or vertical mounting, tabletop or on-wall
• Recessed push-style binding posts, accommodating banana jacks
• Gloss black finish with MartinLogan's signature perforated grille

Specifications

• Frequency response: 70–23,000Hz ±3dB
• Recommended amplifier power: 20–180 watts per channel
• Horizontal dispersion: 80°
• Vertical dispersion: 80°
• Sensitivity: 89dB/2.83V/meter
• Impedance: 4Ω, compatible with 4, 6, or 8Ω rated amplifiers
• Crossover frequency: 3,000Hz
• High frequency transducer: 1in x 1.4in (2.6cm x 3.6cm) Folded Motion transducer with 5.25in x 1.75in (13.3cm x 4.4cm) diaphragm
• Low frequency transducer: two 4in (10.2cm) paper cone woofers with stamped steel basket, non-resonant asymmetrical chamber, rigid structured dust cap, sealed
• Components: custom air core coil and low DCR steel laminate inductors, polyester film capacitors in series, low DF electrolytic capacitors in parallel, system thermal/current protection
• Inputs: push style with banana jacks
• Weight: 8.5lb (3.85kg)
• Dimensions: 5.6in x 22.25in x 5.2in (14.2cm x 56cm x 13.2cm)
