Marantz PM-6007 - Integrated Amplifier

Description

The Marantz PM6007 is a 2-channel integrated amplifier delivering 45W per channel via a current feedback design and toroidal power transformer. It features a 192kHz/24-bit AK4490 DAC, a built-in MM phono preamp, and digital inputs for connecting both analog and digital sources.

Features

• Current feedback amplifier with high current power supply
• Reference-class AK4490 DAC, up to 192kHz/24-bit resolution
• Marantz HDAM-SA3 discrete circuit modules for lower distortion
• 5 analog inputs, 2 optical and 1 coaxial digital input
• Two-mode digital filter (slow/sharp roll-off) for optical/coaxial input
• Built-in MM phono preamp with FET input stage
• Subwoofer output with fixed 150Hz low-pass crossover
• Speaker A/B switching
• Toroidal transformer for low electromagnetic radiation and vibration

Specifications

• Power output: 45W (8 ohms) / 60W (4 ohms) RMS
• Frequency response: 10 Hz to 70 kHz
• THD: 0.08%
• Damping factor: 100
• Input sensitivity: MM 2.2mV/47kΩ; High level 200mV/20kΩ
• Signal to noise ratio: MM/MC 83dB; High level 102dB (2V input)
• Power consumption: 155W operational / 0.3W standby
• Dimensions (W x D x H): 440 x 370 x 105 mm
• Weight: 7.6 kg
