Marantz AV7706 - 11.2 Channel 8K Pre-Amplifier

AED 10,475.00(Exc. Tax)

AV7706 The AV7706 is made for home cinema enthusiasts who want everything, versatility, flexibility and musicality. The Pre-Amplifier expertly handles any kind of high-resolution stereo or multichannel audio format. Enjoy superb...

Description

AV7706

The AV7706 is made for home cinema enthusiasts who want everything, versatility, flexibility and musicality. The Pre-Amplifier expertly handles any kind of high-resolution stereo or multichannel audio format. Enjoy superb surround sound audio quality from the latest formats including Dolby Atmos, DTS:X, IMAX Enhanced and Auro-3D. The AV7706 enhances audio quality by delicately handling all signals via the Marantz's own current feedback HDAMs amplifier modules, before passing them to the high-quality 11.2 channel XLR or 11.2 RCA outputs and separate power amps.

Enjoy exquisite video performance thanks to the latest HDMI technologies such as 8K/60Hz pass-through or upscaling, various HDR format support including HDR10, HDR10+, Dolby Vision, Hybrid Log-Gamma (HLG) and Dynamic HDR, as well as the latest gaming technologies such as 4K/120Hz pass-through, Variable Refresh Rate (VRR) and Auto Low Latency Mode (ALLM).

Extensively tuned by world-renowned sound acousticians at the most state-of-the-art facilities, the new Marantz AV7706 leverages decades of experience in Hi-Fi to drive exceptional, audiophile-quality surround sound for all your entertainment.

Key Features

  • Premium-performance AV pre-amplifier with 11.2 channel XLR pre-out for maximum home cinema flexibility and musical fidelity.
  • Featuring the most advanced three-dimensional audio formats: Dolby Atmos, Dolby Atmos Height Virtualization Technology, DTS:X and DTS Virtual:X, IMAX Enhanced and Auro-3D processing are all supported to allow you to listen to all of your favourite audio styles.
  • Advanced 32-bit Conversion on All Channels: For optimum fidelity and the widest dynamic range with lowest distortion, the AV7706 features advanced reference-class 32-bit AKM D/A converters on all channels. This ensures consistent high fidelity and precise channel matching across all channels for the ultimate listening experience.
  • Exclusive components elevate the Marantz sonic signature: Marantz proprietary HDAM circuit boards, Current Feedback circuitry, AKM AK4458 32-bit D/A converters, and Hybrid PLL Clock Jitter Reducer produce more detailed, dynamic sound. Audyssey MultEQ XT32 automatized setup and room acoustic correction with Dynamic Volume, Dynamic EQ, Sub EQ HT and Low Frequency Containment deliver a full-range balance, including deep bass with improved definition.
  • 8K/60Hz and 4K/120Hz pass-through support for every entertainment need: With the latest technology in HDMI support, enjoy 8K quality video from your 8K source devices or with 8K upscaling from Full HD or 4K sources.
  • HDMI eARC Object-Based Audio Support: eARC (Enhanced Audio Return Channel) supports the transmission of 3D audio from your TV with a single HDMI connection for the simplest setup.
  • The greatest technology for home cinema: Support for the latest HDR formats including HDR10, HDR10+, HLG, Dolby Vision, 4:4:4 colour resolution and BT.2020, as well as Dynamic HDR provides exceptional picture quality for brightness, clarity and contrast.
  • The Next Level in Gaming: Enjoy your gaming with 4K/120Hz pass-through, as well as Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM), which reduces or eliminates lag and frame tearing.
  • HEOS Built-in: Almost unlimited music sources: Stream from music services like Spotify Free and Premium, Amazon Music HD, Tidal and more, or stream directly from smart devices via AirPlay 2 or Bluetooth
  • Phono EQ Stage with HDAM: The HDAM component of the Marantz AV7706 outperforms op-amp solutions due to its high speed and maintains a clean audio signal for exceptional sound performance.
  • Dual Subwoofer Outputs: Surround yourself with even, accurate bass. The AV7706 features two subwoofer outputs to smooth low frequencies and improve bass dispersion, avoiding peaks and audible dips. Connected subwoofers can be calibrated independently thanks to Audyssey Sub EQ HT technology for more seamless bass performance tailored to your room.

The next chapter in movie entertainment

The new AV7706 offers the highest-quality, crystal-clear viewing experience. Enjoy your movies with 8K/60Hz pass-through or upscaling, as well the latest in HDMI technology like Dynamic HDR and Quick Media Switching (QMS), which is used in movies to eliminate video delay.

Masterful 8K HDMI Connectivity

The new Marantz AV7706 includes eight HDMI inputs and three outputs for all your favourite sources. With one dedicated 8K HDMI input to support 8K/60Hz or 4K/120Hz pass-through capability with 4:4:4 Pure Color sub-sampling. 4K/120Hz (4:2:0 - 8-bit) Dolby Vision, HLG, HDR10, 21:9 video, 3D and BT.2020 pass-through and HDCP 2.3, the latest in copy protection standards, are supported on all HDMI inputs. Showcasing the latest HDMI technology and specifications, the new AV7706 lets you take your home entertainment up a notch with HDR10+, Dynamic HDR, ALLM, VRR, QMS and QFT support. The video processor is also capable of upscaling your native video source up to 8K quality.

Bluetooth, Wi-Fi and AirPlay 2 Capability

A dual antenna system lets you stream the most popular music services via Bluetooth, Wi-Fi, and AirPlay 2. Listen to your playlists on Spotify, TuneIn, Deezer and more. Use AirPlay 2 to enjoy Apple music with ease.

Bluetooth Audio Transmission

Enjoy your favourite audio without waking your whole home by transmitting the audio coming from your AV Pre-Amp to your Bluetooth headphones. The AV7706 even allows you to play the audio on both Bluetooth headphones and connected speakers simultaneously. If you have a family member or a friend who is hearing impaired, we recommend this setup.

SPECIFICATIONS

Wi-Fi

Dual-Band (2.4/5 GHz)

Bluetooth

Yes

AirPlay

Yes, AirPlay 2

Supported File Types

MP3, 24-Bit/192 kHz WAV, 24-Bit/192 kHz ALAC, 24-Bit/192 kHz FLAC, 24-Bit/192 kHz WAV, 2.8 & 5.6 MHz DSD

Inputs

  • 8 x HDMI (1 Front)
  • 3 x 3RCA Component Video
  • 4 x RCA Composite Video (1 Front)
  • 2 x Optical TOSLINK
  • 2 x Digital Coaxial
  • 6 x Stereo RCA (1 Front)
  • 1 x Stereo RCA Phono with Ground Screw
  • 1 x 7.1-Channel RCA

Outputs

  • 3 x HDMI
  • 1 x 11.2-Channel XLR Pre-Out
  • 1 x 11.2-Channel RCA Pre-Out
  • 2 x Stereo RCA Pre-Outs (Zone 2/3)
  • 1 x 1/4" / 6.35 mm Headphone (Front)

Other Ports

  • 1 x USB Type-A (Front)
  • 1 x RJ45 Ethernet LAN
  • 1 x RCA Remote In
  • 1 x RCA Remote Out
  • 2 x 1/8" / 3.5 mm Trigger Out
  • 1 x 1/8" / 3.5 mm IR Flasher In
  • 1 x DE9 RS-232C
  • 2 x Wireless Antenna Terminals
  • 1 x FM Antenna In
  • 1 x AM Antenna In
  • 1 x 1/8" / 3.5 mm Setup Mic In (Front)

Audio Formats

Native Formats: Dolby Atmos, Dolby TrueHD, DTS:X, Auro-3D, IMAX Enhanced

Upsampling Technologies: Dolby Atmos Height Virtualization Technology, Dolby Surround, DTS Neural:X, DTS Virtual:X, Auromatic,

DAC

32-Bit AKM D/A Converters on All Channels

HDR Support

HDR10, HDR10+, Dolby Vision, HLG Pass-Through

HDCP Version

2.3

Upscaling

HD to 8K UHD, SD to HD

Dimensions (W x H x D)

17.38 x 7.38 x 15.5" / 44.13 x 18.73 x 39.37 cm
