Marantz AV7705 - 11.2 Channel Pre-Amplifier

AED 9,999.00

AV7705 Enjoy streaming audio and immersive multi-channel sound with your amplifier and the Marantz AV7705 11.2-Channel HEOS Preamplifier. It sports an 11.2-channel XLR pre-out and features Dolby Atmos and DTS:X compatibility...



Enjoy streaming audio and immersive multi-channel sound with your amplifier and the Marantz AV7705 11.2-Channel HEOS Preamplifier. It sports an 11.2-channel XLR pre-out and features Dolby Atmos and DTS:X compatibility for object-based audio decoding. Built-in Bluetooth and AirPlay 2 support allows the preamplifier to wirelessly stream music from compatible sources, such as smartphones and tablets.

Onboard Wi-Fi and Ethernet connectivity allows the AV7705 to access music from your connected computer or NAS. Amazon Alexa, Google Assistant, Siri, and compatibility enables you to control certain functions of the preamplifier with just your voice through your compatible devices. With eight HDMI inputs and three outputs, the AV7705 can act as a video switcher for your HD source components. It will pass through HDR UHD 4K signals as well as HDR10, Dolby Vision, and HLG HDR formats. The preamplifier also has a USB port for accessing media stored on USB flash drives.

Key Features

  • 11.2 channel XLR pre-out; 11.2 channel RCA pre-out
  • 8 HDMI inputs (incl. 1 front) with full HDCP 2.2 support; 3 HDMI outputs (incl. Zone 2)
  • 4K/60 Hz full-rate pass-through, Dolby Vision compatibility, HDR, HLG and BT.2020
  • Advanced video processing with analog to HDMI conversion; SD to HD/4K upscaling
  • Dolby Atmos, DTS:X (up to 7.1.4 with an external 2ch amplifier), Auro-3D and DTS Virtual:X for height virtualization effects
  • eARC (Enhanced Audio Return Channel) support via firmware update supports the most advanced surround and object-based audio formats via single HDMI connection between AVRs and compatible TVs
  • Stream music from Internet Radio, Spotify Connect, Pandora, SiriusXM, Amazon Music, TIDAL, Deezer and more with Bluetooth, Airplay2 or HEOS built-in
  • Built-in Wi-Fi with 2.4GHz/5GHz dual band support
  • Enjoy multi-room whole-home audio streaming with HEOS technology
  • Amazon Alexa voice control via the HEOS Home Entertainment skill
  • Marantz 2016 AVR remote app for control over the latest generation of Marantz network AV Receivers. Available on iOS and Android
  • High resolution DSD (2.8/5.6MHz), FLAC, ALAC and WAV support
  • AKM AK4458 32-bit D/A converters, HDAM circuit boards and Current Feedback circuitry for optimum fidelity and maximum dynamic range
  • Suite of Audyssey room correction software: Audyssey MultEQ XT32, Dynamic Volume and Dynamic EQ, LFC and Sub EQ HT
  • Third-party integration and IR remote control, RS-232C serial port and Creston Connected for external control
  • Seamless out-of-the-box experience with Quick Start Guide, guided Setup Assistant and Marantz AVR Remote App

Object-Based Audio Format Support

Dolby Atmos, DTS:X, Auro-3D, DTS Neural:X, and DTS Virtual:X are designed to create realistic surround sound, positioning and moving individual sounds to nearly any virtual point in your room, including overhead, using up-firing or dedicated overhead speakers.

HDMI eARC Object-Based Audio Support

eARC (Enhanced Audio Return Channel) supports the transmission of 3D audio from your display's apps over a single HDMI cable for a simple setup.

IMAX Enhanced Technology

IMAX Enhanced certification designates that the AV7705 meets certain audio and video performance criteria set by a committee of IMAX and DTS engineers and A/V technical specialists. These criteria include image, sound, scale, and content quality. Onboard IMAX calibrated modes are set and approved by Hollywood colorists to help provide enhanced picture and sound for HDR UHD content.

Hi-Res Audio

Enjoy the fidelity of high resolution audio with the ability to decode up to 24-bit/192 kHz ALAC, FLAC, and WAV lossless files, as well as DSD 2.8 MHz and 5.6 MHz tracks (the audiophile format of SACD). Play hi-res music, MP3s, and other popular file types via the front-panel USB port and network sources.

32-Bit D/A Conversion on All Channels

For augmented fidelity and dynamic range with low distortion, the AV7705 features 32-bit AKM D/A converters on all channels, helping to ensure high fidelity and precise channel matching across all channels.

Marantz HDAM (Hyper Dynamic Amplifier Module) and Current Feedback Topology

The AV7705 features multiple HDAM modules, which are engineered to provide a fast slew rate, wideband performance, and enhanced dynamic range for optimum sound quality. Current Feedback technology, rather than the typical voltage feedback configuration, helps provide a wide, closed-loop bandwidth and steep slew rate to further augment fidelity with wideband audio sources.

Phono EQ Stage with HDAM

The HDAM is designed to outperform op-amp solutions with its higher speed, helping to keep the audio signal clean and tuned for enhanced sound performance.

Dual Subwoofer Outputs

The AV7705 features two subwoofer outputs to help smooth out low frequencies and enhance bass dispersion, mitigating peaks and audible dips.

Designed for Easy Setup

Once you connect your display to the AV7705 via HDMI, the Marantz Setup Assistant appears on the screen to guide you through the setup, helping you establish settings to help achieve the best sound quality for your configuration.



  • Version: 3.0 + EDR (Enhanced Data Rate)
  • Supported Profiles: A2DP 1.2, AVRCP1.5
  • Supported Codec: SBC
  • Range: 98.4' / 30 m in line of sight
  • Transmission Range (A2DP): 20 Hz to kHz


Yes, AirPlay 2


Dual-band (2.4/5 GHz) Wi-Fi 4 (802.11a/b/g/n)

Wi-Fi Security

WEP 64-bit, WEP 128-bit, WPA/WPA2-PSK (AES), WPA/WPA2-PSK (TKIP)

Supported File Types

WMA, MP3, WAV 192/24, MPEG-4 AAC, FLAC, FLAC HD 192/24, ALAC 192/24, DSD, Apple Lossless


  • 8 x HDMI (1 front)
  • 3 x RCA component video
  • 4 x RCA composite video (1 front)
  • 2 x optical TOSLINK
  • 2 x digital coaxial
  • 6 x stereo RCA (1 front)
  • 1 x stereo RCA phono with ground screw
  • 1 x 7.1-channel RCA
  • 1 x USB (front)


  • 3 x HDMI
  • 1 x 11.2-channel XLR pre-out
  • 1 x 11.2-channel RCA pre-out
  • 2 x stereo RCA pre-outs (Zone 2/3)
  • 1 x 1/4" / 6.35 mm headphone (front)

Other Ports

  • 1 x RJ45 Ethernet LAN
  • 1 x RCA remote in
  • 1 x RCA remote out
  • 2 x 1/8" / 3.5 mm trigger out
  • 1 x 1/8" / 3.5 mm IR flasher in
  • 1 x RS-232C
  • 2 x wireless antennas
  • 1 x FM antenna in
  • 1 x AM antenna in
  • 1 x 1/8" / 3.5 mm setup mic in (front)

Input Sensitivity

  • Analog Audio: 200 mV
  • Phono: 2.5 mV

Rated Output

  • Unbalanced RCA: 1.2 V
  • Balanced XLR: 2.4 V
  • D/A: 2 V (at 0 dB playback)

Input/Output Level and Impedance

  • Composite, Component Y-Signal: 1 Vp-p, 75 Ohms
  • Component PB/CB, PR/CR Signal: 0.7 Vp-p, 75 Ohms

Audio Formats

Dolby Atmos, Dolby TrueHD, Dolby Surround, DTS:X, DTS Neural:X, DTS Virtual:X, DTS HD Master, Auro-3D, Aurmatic, IMAX Enhanced


32-bit AKM D/A converters on all channels

Frequency Response

Analog: 10 Hz to 100 kHz (+1, -3 dB, direct mode)

Signal to Noise Ratio

Analog: 105 dB (IHF-A weighted, direct mode)


  • Phono: 74 dB (A weighting, with 5 mV input)
  • Digital: 102 dB
  • Analog: 0.005% (20 Hz to 20 kHz, direct mode)
  • Phono: 0.03% (1 kHz, 3 V)

Total Harmonic Distortion

D/A Output: 0.008% (1 kHz, at 0 dB)

Dynamic Range

D/A Output: 100 dB


RIAA: ±1 dB (20 Hz to 20 kHz)

HDR Support

HDR10, Dolby Vision, HLG pass-through

HDCP Version



Up to 4K/60p, analog to HDMI, HDMI to HDMI

Frequency Response

  • Composite Video: 5 Hz to 10 MHz (0, -3 dB)
  • Component Video: 5 Hz to 60 MHz (0, -3 dB)

Tuner Bands


Frequency Range

  • AM: 520 to 1710 kHz
  • FM: 87.5 to 107.9 MHz


  • Effective, AM: 18 μV
  • Effective, FM: 1.2 μV (12.8 dBf)
  • 50 dB, Mono FM: 2.8 μV (20.2 dBf)

Signal to Noise Ratio

  • FM, Mono: 70 dB (IHF-A weighted, direct mode)
  • FM, Stereo: 67 dB (IHF-A weighted, direct mode)


  • FM, Mono: 0.7% (1 kHz)
  • FM, Stereo: 1% (1 kHz)

Dimensions (W x H x D)

  • With Antennas Down: 17.38 x 7.38 x 16.25" / 440 x 185 x 411 mm
  • With Antennas Up: 17.38 x 9.75 x 16.25" / 440 x 247 x 411 mm


22.93 lb / 10.4 kg
